| Business Type | Manufacturer, Exporter, Supplier, Retailer |
| Type | Automatic |
| Voltage | 415 V |
Features :
- Heavy duty zinc coated frame
- Covering panel made from S. S. 304 quality
- Two stage homogenization
- Low RPM Triplex plunger pump
- Pressure adjustment by hand wheel with imported springs
- Sterlite coated seat with ball type NRV for suction and discharge valves
- Sterlite coated Homogenizing Valve
- Imported S. S. diaphragm type sanitary design pressure gauge
- High strength steel eccentric shaft and connecting rod assembly
- Splash lubricating system
- Electrical panel with over pressure tripping safety
- All product contact parts of S. S. 304
Specifications
| Model | HM 100 | HM-150 | HM-300 | HM-500 | HM1000 |
| Capacity, l/hr | 100 | 150 | 300 | 500 | 1000 |
| Motor, kW | 1.5 | 2.25 | 3.75 | 5.5 | 9.3 |
| Max. working pressure,bar | 240 | 240 | 240 | 240 | 240 |
| No. of pistons | 3 | 3 | 3 | 3 | 3 |
| Length, mm | 1000 | 1000 | 1030 | 1060 | 1260 |
| Width, mm | 730 | 730 | 730 | 750 | 800 |
| Height, mm | 1050 | 1100 | 1100 | 1100 | 1270 |
